**JUNCTION BOX EXPLOSION PROOF - Ex d - ALUMUNIUM**

T. amb.

- 40°C/+ 60°C

Category

2 GD

2 (1) GD

2 (2) GD

M2

Directive

9/94/CE (ATEX)

Standard reference

CENELEC EN50014/18/20

EN50281-1-1

EN60529

EJB / CCF housings allow the realization of control panels with various types of controls and/or warning signals positioned on the cover.

EJB / CCF housings allow the possibility to place several threaded holes on the side wall and retain various types of electrical appliances such as fuses, transformers, switch-gear, relays, insulations devices, magnetic starters with overload and undervoltage protection, insulating switches, circuit breakers and differential switches; intrinsecally safety barriers can also be included.

The maximum electrical rating for the CCF 3 housing are: 660V. – 800A.

Complex assemblies can also be achieved by combining various housings, control modules with self-supporting frames.

Threading and inlets:

The inlets are custom made on the side walls or on the base. Different layouts are available.

The standard thread is Gas Conic type GK UNI 6125 (UNI339 - ISO 7/1).

The following custom made threads are also available:

- Gc UNI 338 (ISO R 228),
- NPT ANSI B.2.1,
- metric ISO 965/I
- and PG DIN40430

Materials and treatments:

- Cast iron UNI/ISO 185 Q200 (G20 UNI 5007);
- other materials available: INOX AISI 304/316,
- aluminium alloy G Al Si 13 UNI 4514 .
- Electrolytic zinc plating procedure.
- External nitro painting RAL 9006 or RAL 7034
